30000BPH Aseptic Cold Filling Machine For Beverage Juice
| Material: | Stainless Steel | Process: | Pressure Filling System |
|---|---|---|---|
| Certification: | GB/T19001-2000 | Type: | Filling Machine |
| Applicable Products: | Fruit Juice, Tea Drinks, Protein Drinks, Dairy Products, Etc. | Filling Temperature: | 4~35℃ |
| Capacity Range: | 30000BPH | Filling Valve: | Adopt Imported Flow Meter Valve/imported Electronic Weighing Valve According To Customer Needs |
| High Light: | 30000BPH Aseptic Cold Filling Machine, 30000BPH Aseptic Juice Filling Machine, 24000BPH Aseptic Cold Filling Machine | ||
30000BPH Aseptic Cold Filling Machine For Beverage Juice
Aseptic Cold Filling Machine Applicable For Various Kinds Of Beverage and Juice
Applicable products: acidic or low-acid products such as fruit juice, tea drinks, protein drinks, dairy products, etc.
Filling temperature: 4~35℃
Capacity range: 15000–36000B/H.
Filling valve: adopt imported flow meter valve/imported electronic weighing valve according to customer needs
Specifications of Bottled Water Filling Machine
| Model | Number of Bottle Dumping Clip | Number of Bottle Rinsing Clip | Number of Filling Valve | Number of Capping Head | Capacity (BPH) |
Bottle Size |
Outline Dimensions (mm) | Quality (Kg) | Remark | ||
| Diameter (mm) | Height (mm) | Volume (ml) | |||||||||
| GWJX18D | 90*2 | 80 | 80 | 18 | 36000 | Φ60-Φ95 | 150-315 | 350-1500 | 19500x 8000x 4000 | 30000 | Split Type |
Features
Our aseptic cold filling line is modularly constructed for great flexibility. It combines the dumping machine, rinser, filler and capper into one unit, and the part above the table-board is full closed by shielding can.
Our aseptic cold filling line is equipped with centralized lubrication system.
Automatic control of CIP and SIP operations is realized.
The inside of of pipeline and valve in contact with material meets the related sanitation standard.
Quality Control
To guarantee the excellent performance of our beverage production lines and beverage machinery, we introduce advanced technology from Germany and Italy, and constantly improve our production technology of liquid filling. Apart from that, free trainings are offered to our employees to help them improve technical skills. In addition, we strongly believe that beverage production lines and beverage machines with high pass rate and reliable quality can effectively reduce production cost. Thus, we strictly implement product inspection in every step of production, from raw material acquisition to shipping our finished products, to ensure the quality and pass rate. Besides, much attention is also placed on perfect management system and high quality employees for a higher working efficiency.
