SS316 Auto Juice Beverage Can Filling Machine

release time
Update:Jun, 12 /2023
author
words
Pageviews:178

SS316 Auto Juice Beverage Can Filling Machine

Material: Stainless Steel / SS316 Process: Gravity Filling System
Certification: GB/T19001-2000 Type: Filling Machine
Filling Valve: Gravity Mechanical Valve Or Customer Needs Capacity: 12000-48000bph
Applicable Bottle Type: 180ml-500ml Application: Juice, Tea
Function: Juice Can Filling Machine
High Light: SS316 Beverage Can Filling Machine, SS316 Juice Can Filling Machine, SS316 Auto Craft Can Filling Machine

Auto Craft SS316 Juice Beverage Can Filling Machine



Automatic Beverage Juice Can Filling Sealing Machine

Our FY series easy-opening production line is specially designed for filling non-carbonated beverages, such as fruit juice, tea beverage, vegetable juice, etc. Just divide it into three pieces.

FY series easy-opening can filling machine is specially designed and manufactured for filling non-carbonated beverages such as fruit juice, tea beverage, vegetable juice, etc. into three-piece cans.

Specifications

Capacity: A-12000 bottles/hour ----48000 bottles/hour (500ml)
Applicable bottle type: 180ml-500ml

Applicable products: mineral water, juice
Refueling valve: According to customer needs, use mechanical valve.

Filling temperature: 85~88℃

Model

FY380

FY1000

Production Capacity (C/M)

300-350

800

Filling Valve

36

60

Can Height

52-300

45-200

Can Diameter

53-110

49.5-65

Motor Power

Transmitted by capper



Weight

2800

3550

Dimensions

1720×1860×1900

2730×1905×1800



Model

FY6H

FY12H

Production Capacity(C/M)

300-350

800

Capping Head Number

6

12

Can Height(mm)

52-300

45-200

Can Diameter(mm)

53-110

49.5-65

Motor Power

7.5

22.5

Weight

3000

3700

Dimensions

2800×1000×2400

1450×1120×2180





Features


1. The outside surface of machine and all the parts in contact with the filling material are made of superior stainless steel which not only ensures beautiful machine appearance but also food safety and hygiene

2. The filler is driven by capper which helps keep synchronization between the filler and capper.

3. The can filling line is easier to assemble, dismantle and clean.

4. PLC control and frequency conversion are adopted for easy operation and convenient adjustment.




Certificates

1. Our beverage machinery is approved as qualified products for seven years by Chinese beverage industry association.
2. Our company is approved as excellent supplier of filling equipment four times by Chinese beverage industry association.
3. Our company is entitled "Star Enterprise" by Chinese food and packaging machinery industry association.
4. Our company is approved as the enterprise technical center of Zhangjiagang Province.
5. Our company obtains ISO9001:2000 International Quality Management System Certification.
6. Our company is awarded as demonstration enterprise of national CAD application engineering by Ministry of Science and Technology of China.
7. All our products are awarded as CE certification.
8. Our company becomes the vice chairman of Chinese food and packaging machinery industry association.

FAQ

Q: What are the Primary Products of Your Company?
A: Our products mainly include water production line, juice production line, tea production line, water filling machine, juice filling machine, tea filling machine, and more.

Q: Where is Your Beverage Machinery Applied to?
A: Our beverage production lines are extensively used for packaging of water, fruit juice, tea drinks, milk beverage, juice with grains, sodas, protein beverages, energy drinks, and more.

Q: What are the Properties of Your Beverage Production Lines?
A: Our beverage machinery adopts automatic operation system which greatly improves the performance and productivity of our packaging machines. They have properties of multifunction, standard design, modularization, digital control system, good compatibility, high accuracy, flexibility, and high working efficiency.

All these measures together enable us to provide high quality carbonated beverage production lines, can filling machines, juice production lines, tea filling machines, etc, at competitive prices.

Q: Do Your Water Production Lines Meet Environmental Protection Requirements?
A: Our water production lines are eco-friendly and energy-saving. They adopt advanced environmental protection technologies from Germany and Italy. All production procedures quite meet the standards of ISO9001: 2000.

Q: Which Countries are Your Beverage Machinery Sold to?
A: Our products are widely exported to U.S.A, Russia, England, Canada, Japan, Egypt, Mexico, South Africa, North Korea, Indonesia, Mongolia, Malaysia, Dominica, Nigeria, Libya, Turkey, Kazakstan, Iran, Yemen, Sudan, Vietnam, Bengal, Burma, Serbia, Macedonia, Lebanon, Congo, Syria, Venezuela, Iraq, Saudi Arabia, and Kenya.

Q: What Kind of After-sale Services does Your Company Provide?
A: Installation guides, device debugging and technical trainings are offered to our global customers to help them make full use of our water production lines, tea filling machines, beverage production lines, and other beverage machinery.
