Ergonomic Design 1500ml Bottle Blow Molding Machine

Model: BCP-12B Bottle Volume: 300-1500ml
Production Capacity: 24000BPH (500ml) Diameter Of Bottle: 35-110mm
Height Of Bottle: 120-330mm Dimensions Of Machine: 7100×4000×3980mm
Weight Of Machine: 16300kg Blowing Pressure: 3.5-4.0Mpa
Working Pressure: 0.8-1.0Mpa Using Voltage: 380V.50HZ
Installed Power: 244kw Actual Operating Power: 120Kw
Mould Cooling: 35HP Lubrication Standard: 35-60#
High Light: 1500ml Bottle Blow Molding Machine, 2000ml Bottle Blow Molding Machine, 380V Bottle Blow Moulding Machine

Ergonomic Design 1500ml Bottle Blow Molding Machine



Accurate And Convenient Changing Of Bottle Size Blow Moulding Machine

Automatic PET Blow Molding Machine

Our BCP series automatic PET blow molding machine is designed and manufactured according to our decades of experience, and the production capacity is from 15000 to 48000B/H. It has the advantages of convenient setting, ergonomic design, high efficiency, simple operation and strong flexibility. In addition, our PET blow molding machine can be customized according to customers' specific requirements. As an experienced blow molding machine manufacturer in China, Baiguan Group provides customers with training and maintenance services to ensure the smooth operation of our products.

Features:

  1. Three-blowing and two-recovery energy-saving technology: pressure difference cascade use, saving compressed air and energy about 40%.
  2. Mechanical sealing safeguard technology: The sealing track ensures that the sealing cylinder is raised quickly and absolutely, which is mainly used to ensure the safety of the high-speed blowing machine.
  3. Pre-blowing proportional valve control technology: The operation panel controls more precise process guarantees and energy saving measures.
  4. Manipulator fork automatic clamping technology: the manipulator fork automatically opens and clamps the bottle mouth, so as to ensure that the bottle or preforms is more stable and not scratched.
  5. Heating and ventilation independent module: improve the modularization, general utilization and standardization, realize the module inlay technology, easy to install, maintain and adjust the process.
  6. Servo stretching technology: it can quickly and accurately control the up and down moving speed and position of the stretching rod, realizing that stretch bottles of various height specifications by the same stretching rod, meet the stretching requirements of various preforms and solve the problem that some preforms are not easy to stretch.
  7. Heating lamp monitoring technology: real-time monitoring of heating lamps in each zone and layer of the heating oven, and interconnection with the operation panel, which can quickly and accurately check the use of heating lamps in each zone and layer of the heating oven.
  8. Cooling water circuit temperature inspection technology: real-time inspection of the cooling water inlet temperature, interconnection with the operation panel, data visualization, and accurate adjustment of the cooling water temperature according to the cooling effect of different bottle types.
  9. High-speed, silent, low-consumption, artware



Specifications of Rotary Blow Molding Machine



Item BCP-8B BCP-10B BCP-12B BCP-14B
Bottle Volume Range 300-1500ml 300-1500mm 300-1500mm 300-1500mm
Production Capacity 16000BPH (500ml) 20000BPH (500ml) 24000BPH (500ml) 28000BPH (500ml)
Max Diameter of Bottle 110mm 110mm 110mm 110mm
Max Height of Bottle 330mm 330mm 330mm 330mm
Dimensions of Machine 7100×4000×3980mm 7100×4000×3980mm 7100×4000×3980mm 7500×4200×3980mm
Weight of Machine 12000kg 13400kg 16300kg 18000kg
Blowing Pressure 3.5-4.0Mpa 3.5-4.0Mpa 3.5-4.0Mpa 3.5-4.0Mpa
Air consumption 5m3/min 6m3/min 8m3/min 9m3/min
Using Voltage 380V.50HZ 380V.50HZ 380V.50HZ 380V.50HZ
Installed Power 168kw 206kw 244Kw 244Kw
Average energy consumption 80Kw 100Kw 120Kw 120Kw
Mould Cooling 30HP 30HP 35 HP 35HP
Available Material PET PET PET PET





Applications

Our automatic PET blow molding machine is suitable for use as water bottle molding machine, oil bottle moulding machine, juice bottle molding machine, and others.

HZM Packaging Machinery Co., Ltd. is a comprehensive liquid beverage packaging solution provider specializing in design, manufacturing, sales and service. It has been deeply involved in the packaging machinery industry for nearly 10 years. Its service areas are widely used in beverages, dairy products, and condiments. It is one of the manufacturers with the highest level of technology and the most complete varieties of equipment for the production of liquid beverages in many packaging industries in China, such as alcohol, daily chemicals.

FAQ

Q: What are the Primary Products of Your Company?
A: Our products mainly include water production line, juice production line, tea production line, water filling machine, juice filling machine, tea filling machine, and more.

Q: Where is Your Beverage Machinery Applied to?
A: Our beverage production lines are extensively used for packaging of water, fruit juice, tea drinks, milk beverage, juice with grains, sodas, protein beverages, energy drinks, and more.

Q: What are the Properties of Your Beverage Production Lines?
A: Our beverage machinery adopts automatic operation system which greatly improves the performance and productivity of our packaging machines. They have properties of multifunction, standard design, modularization, digital control system, good compatibility, high accuracy, flexibility, and high working efficiency.

All these measures together enable us to provide high quality carbonated beverage production lines, can filling machines, juice production lines, tea filling machines, etc, at competitive prices.

Q: Do Your Water Production Lines Meet Environmental Protection Requirements?
A: Our water production lines are eco-friendly and energy-saving. They adopt advanced environmental protection technologies from Germany and Italy. All production procedures quite meet the standards of ISO9001: 2000.

Q: Which Countries are Your Beverage Machinery Sold to?
A: Our products are widely exported to U.S.A, Russia, England, Canada, Japan, Egypt, Mexico, South Africa, North Korea, Indonesia, Mongolia, Malaysia, Dominica, Nigeria, Libya, Turkey, Kazakstan, Iran, Yemen, Sudan, Vietnam, Bengal, Burma, Serbia, Macedonia, Lebanon, Congo, Syria, Venezuela, Iraq, Saudi Arabia, and Kenya.

Q: What Kind of After-sale Services does Your Company Provide?
A: Installation guides, device debugging and technical trainings are offered to our global customers to help them make full use of our water production lines, tea filling machines, beverage production lines, and other beverage machinery.
