4.5t/H Hs Series Soft Drinks Beverage Gas Plc Co2 Mixer Machine

High Light: 4.5t/h co2 mixer, plc co2 mixer, plc beverage mixer machine

Beverage mixer (carbonated drinks mixer)is used for producing all carbonated beverages (water, syrup, and CO2 mixing), for example lemon, coca cola, fruits juice and so on. It is the main equipment in whole beverage production line. (Especially for middle and higher standard beverage production).

Features

1. Automatic with Alarm:The pressure in all tank and the liquid level of the machine are all controlled automatically with PLC.Once a error occurs,the alarm lamp will light and the alarm ring will sound and the mixer will stop automatically.

2.Easy operation and regulation:The operation of the mixer is especially convenient.Only turn around the buttons according to the pre-set program,the normal operation can be carried out.The production capacity,water-sugar proportion and gas content can be adjusted without exchanging and parts.

3.Even mixing and accurate proportion:One time mixing process is adopted,so the mixture is even.The mixing proportion of water and sugar is strictly controlled with measuring needle valve with fine regulation.Its precision can reach about 5%.

4.Enough gas content:The mixer adopts vacuum desoxidation technology at normal temperature.Its desoxidation ratio reaches above 90%.It has a baffle heat exchanger to cool the sugar-water mixture and carry out twice carbonating,So its carbon content is especially high.

Basic parameter



  1. Production capacity(t / h)
4.5-12
  1. CO2 content(g)
12g/L≥g≥4.9g/L
  1. Drinks outlet pressure(MPa)
0.3-0.5
  1. Purified water inlet pressure(MPa)
0.2-0.3
  1. Max. pressure of CO2 inlet(MPa)
0.7-0.8
  1. CO2 purity
>99.99%
  1. CO2 temperature(℃)
≤10
  1. Syrup inlet temperature(℃)
≤8
  1. Purified water inlet temperature(℃)
≤4
  1. Refrigerant inlet temperature(℃)
0
  1. Purified water inlet diameter(mm)
φ50.8x1.5
  1. Syrup inlet diameter(mm)
φ38.1x1.5
  1. CO2 inlet diameter(mm)
φ19x1.5
  1. Vacuumize
have
  1. Compressed air exhaust (when 0.6Mpa)
About 100L/min
  1. Dimension(mm)
2400X1500X2500
  1. Weight(kg)
About 2000
  1. Power(KW)
10
  1. Power supply
3N--50Hz,AC380
